Control system > switch > push switch > push switch

push switch

Item No. :301-100-103-001

Information :

Technical Information
Operating voltage (nominal) 12V of 24V
Operating ambient temp -30ºC tot + 70ºC
Bulb 0,9W (12V of 24V)
Belasting 10mA minimum 15A maximum
Maxium current carrying capability, per contact pair 25A
Maxium current carrying capability, per switch 50A
Electrical lifetime 500.000 cycli
Plugs 6,3x0,8 E-Cu, 5µm Ag. gal.
Dust and Water protection Panelside: IP 67, DIN 40 053
According to ASAE EP 455
